Product Overview
A twin-cylinder 12V portable air compressor kit rated 1080W, delivering up to 300LPM (10.6CFM) and a maximum 150 PSI. Built for 4×4 and RV tyre inflation, the heavy-duty kit includes the compressor, a nylon tool bag, a 6.5ft thick power cable, a 26ft rubber air hose with gauge, three nozzle adapters and a thumb-lock adapter.
Key Features
- 300LPM airflow inflates large truck and off-road tyres quickly
- Digital pressure gauge reads live tyre pressure to +/-1 PSI
- Over-current, over-temperature and over-pressure protection
- Complete kit — bag, cable, hose, gauge and adapters included
- Twin-cylinder design for faster inflation
Typical Applications
Off-road vehicle recovery, winching and towing operations, load securement and general rigging work where a rated connector is required. Always observe the vehicle and equipment manufacturer guidance, and use an appropriate safety factor for the application.
Specifications
| Part No. | CHQB-01 |
|---|---|
| Model Name | Air Pump Kit |
| Rated Power | 1080W |
| Input Voltage | 12.0-13.8V DC |
| Max Current | 90 Amp |
| Max Pressure | 150 PSI |
| Max Air Flow | 300LPM/10.6CFM |
| Material | Aluminium alloy, metal |
| Recommended Use | Tyre inflation |
| Power | Corded electric |
| Air Hose | 26 inch long, with 2 quick couplers |
| Noise Level | 78 dB |
| Over-current Protection | Yes (over 120Amp) |
| Over-temp Protection | Yes (over 105C) |
| Over-pressure Protection | Yes (over 145PSI) |
| Unit Switching | Yes |
| Special Features | Twin cylinder, digital auto shut-off |
| Cylinder Size | 2 x 60 mm |
| 12V Cable Length | 2 m |
| Digital Gauge | Live tyre pressure ±1 PSI |
| PCS/CTN | 1 pc/CTN |
| G.W. / N.W. | 12/11 kg |
| Pack Size | 40x30x30CM / 1 kit |
Specifications, materials, dimensions, applicable standards, packaging and customization options should be confirmed for the selected model and order.
