Product Overview
Aluminium Pulley Block, 25kN — Blue (APB-2023). Compact 6061 aluminium pulley blocks with integrated swivel and stainless bearings. Built for rope access, caving, rescue hauling and high-angle work where a light, compact sheave is required.
Key Features
- 6061-T6 forged body with integrated stainless bearing for smooth rope running
- 25 kN working load handles heavy rope-access hauling loads
- Compact 81 mm width fits standard harness and anchor hardware
Typical Applications
Off-road recovery, vehicle towing, winch operations, rigging and lifting, fleet maintenance and OEM programmes.
Specifications
| Model No. | APB-2023 |
|---|---|
| Material | 6061-T6 forged aluminium, stainless bearing |
| Working Load | 25 kN (5,600 lbs) |
| Sheave Diameter | 44 mm |
| Rope Capacity | 12 mm |
| Side Plate Width | 81 mm |
| Weight | 0.62 kg |
| Certification | CE / EN 12278 |
| Colour | Anodised Blue |
| Certification | ISO 9001 certified manufacturing |
Specifications, materials, dimensions, applicable standards, packaging and customization options should be confirmed for the selected model and order.
