A ball-mount version of the tow bar kit, for fitments using a ball coupler rather than a pintle. The 2″ bar is machined from 6061 aluminium alloy with a 15T (33,069lbs) maximum breaking strength, and the chrome ball itself is rated to 6.8T (14,991lbs). The powder-coated surface resists corrosion.
Kit options
- TCB-A04 — XK-08 + CX-02, 3.65kg/box
- TCB-A05 — XK-01 + CX-02, 4.1kg/box
- TCB-A06 — XK-02 + CX-02, 4.0kg/box
Why buyers choose this
- Separate bar and ball ratings let buyers match the assembly to the weakest component
- Chrome-plated ball resists wear in the coupler
- Accepts 3/4″ D-ring isolators and 7/8″ pins
Specifications
| Breaking Strength | 15T (33,069lbs) |
|---|---|
| Ball Breaking Strength | 6.8T (14,991lbs) |
| Size | 2″ tow bar & ball |
| Material | Aluminium Alloy & Chrome |
| Finish | Powder Coating |
| Box Size | 35.5 x 17 x 8 cm |
| PCS/CTN | 4 boxes/CTN |
| Kit Part Nos. | TCB-A04 / A05 / A06 |
Specifications, materials, dimensions, applicable standards, packaging and customization options should be confirmed for the selected model and order.
