Product Overview
A 13,500lb (6,130kg) rated electric winch built for serious recovery. It uses a pure copper motor and wiring paired with a 600A silver-contact relay, and features a three-stage alloy steel planetary gear for high strength and transmission efficiency. A self-locking clutch brake improves safety during operation.
Key Features
- IP68 waterproof rating — usable in water crossings and heavy rain
- Pure copper motor and 600A silver-contact relay for reliable power
- Self-locking clutch brake adds a layer of safety
- UHMWPE synthetic rope included, 10mm x 24m or 26m
- Two gear ratios: 218:1 faster and 265:1 higher torque
- Wired and wireless remote with 48m range
Typical Applications
Off-road vehicle recovery, winching and towing operations, load securement and general rigging work where a rated connector is required. Always observe the vehicle and equipment manufacturer guidance, and use an appropriate safety factor for the application.
Specifications
| Part No. | DDJP-01 / DDJP-02 |
|---|---|
| Waterproof Rating | IP68 |
| Rated Pull | 13,500 lbs (6,130kg) |
| Motor | 12V 6.0hp/4.5kw sealed DC series-wound motor |
| Control | Wired & wireless remote; with 1 remote + extra wireless remote |
| Control Box | Aluminium, mountable on drum or motor |
| Gear Ratio | 218:1 / 265:1 |
| Clutch | Rotating ring gear (90° rotation) |
| Brake | Auto device in motor bracket, drum stays cool during winching |
| Winch Dimensions | 540 x 160 x 190 / 540 x 158 x 187 mm |
| Pack Size | 600 x 315 x 335 / 615 x 355 x 250 mm |
| Synthetic Rope | 10mm x 24m / 10mm x 26m |
| Fairlead | Aluminium |
| Shipping Weight | 29 kg (63.9lbs) / 28 kg (61.5lbs) |
| Other Info | Gear: 3 stage / Drum 64 x 224 mm |
Specifications, materials, dimensions, applicable standards, packaging and customization options should be confirmed for the selected model and order.
