Product Overview
Heavy Duty Lifting Pulley 2550kg (LTP-25 Series). Self-locking heavy duty lifting pulleys rated to 2,550 kg. The patented ratchet mechanism holds the load without continuous hand pressure, making them ideal for HVAC installation, heavy lifting, material handling and vehicle recovery.
Key Features
- Self-locking ratchet holds the load without continuous hand pressure
- 2,550 kg working load covers HVAC units, machinery and structural components
- Forged alloy body resists creep under sustained static loads
Typical Applications
Off-road recovery, vehicle towing, winch operations, rigging and lifting, fleet maintenance and OEM programmes.
Available Models
The LTP-25 series is available in three body colours and a twin-rope variant. All share the same 2,550 kg working load, 10 mm rope and 35 mm mouth opening — only the finish and rope configuration differ.
Specifications
| Model No. | LTP-25 |
|---|---|
| Material | Forged alloy steel body, alloy steel rope |
| Working Load | 2,550 kg (5,620 lbs) |
| Rope Diameter | 10 mm |
| Rope Length | 4 m |
| Mouth Opening | 35 mm |
| Weight | 8.12 kg |
| Certification | CE certified |
| Colour | Red (also Black and Yellow) |
| Certification | ISO 9001 certified manufacturing |
LTP-25 Series Options
| LTP-25 (Red) | 2,550 kg · 10 mm rope · 4 m · single rope |
|---|---|
| LTP-25B (Black) | 2,550 kg · 10 mm rope · 4 m · single rope, black body |
| LTP-25Y (Yellow) | 2,550 kg · 10 mm rope · 4 m · single rope, yellow body |
| LTP-25D (Twin Rope) | 2,550 kg · twin-rope configuration, dual load path |
Specifications, materials, dimensions, applicable standards, packaging and customization options should be confirmed for the selected model and order.
